CONOTEC

CNT-CS24

· CNT-CS24

> Measurement Range :

Celsius: -20.0°C to 60.0°C (±1°C)

Fahrenheit: -4°F to 140°F (±1°F)

Humidity: 0% to 100% RH (±3%)

> Communication Method : Remote monitoring

> Compact design

> Communication Protocol: RS485 (Modbus RTU)

> Celsius/Fahrenheit: Selectable between °C and °F

제품 문의하기

Dimension	40.6(W) x 20(H) x 62.0(D)
Operating Range	(Celsius) -20.0 ~ 60.0℃(±1℃) (Fahrenheit) -4 ~140℉(±1℉)
Humidity Range	(Humid) 0~100% RH(±3%)
Input sensor	SHT30
Function	Temp. Humi Measurement / 485 Communication (MODBUS)
Setting Method	485 Communication(MODBUS)
Power Supply	DC 5V
Power consumption	20mA(Based on DC 5V)
Ambient Temp/Humi	-20.0 ~ 60.0℃ (-4~140℉) 0 ~ 95% RH(Anti-condensation)
